Dualhead 4K Transmitter

Dualhead 4K Transmitter

The ultra-high definition dual channel 4K fiber optic transmission terminal is a dual channel ultra-high definition seat input in the fiber optic non IP seat collaborative management system, supporting HDMI and MiniDP acquisition, with a resolution of up to 3840x2160@60Hz Through LC dual core fiber optic cables, data access for HDMI, KVM, and 3.5MM audio is achieved, supporting local ring out support. Nodes have bidirectional interaction capabilities for audio, video, and control.



  • Category: KVM Transmitter
  • SKU: SC-CPU-2C4H-SM

Overview

Product Features

1. Adopting a closed-loop fiber optic KVM architecture, video, audio, and control signals can be collected and output controlled through a single fiber optic cable;

2. The input and output nodes adopt high-performance image processing chips, supporting YUV/RGB444 signal format input and output;

3. Fiber optic transmission processing technology that supports lossless non coding and decoding, with single link resolution up to 3840x2160@60Hz , including 1080p60Hz and backward compatibility, providing high-quality image transmission;

4. Supports dual fiber optic and dual power backup, and supports manual or automatic switching between fiber optic links;

5. The node supports analog audio and digital embedded audio mixing transmission, and supports audio synchronization and asynchronous switching;

6. The node has ≥ 2 HDMI input interfaces, ≥ 2 mini DP input interfaces, ≥ 2 HDMI ring out interfaces, ≥ 2 3.5mm stereo audio input interfaces, ≥ 2 3.5mm stereo audio output interfaces, ≥ 4 fiber optic interfaces, ≥ 4 USB interfaces, ≥ 1 Type-C interface, and supports control interfaces such as RS232/RS485/Play/IO/IR, and ≥ 2 external power supply interfaces.


parameter

model

Dualhead Transmitter

Video

Input signal

HDMI ,Mini DP

Input interface

HDMI LOOP OUT

output signal

HDMI type a

Output interface

3840x2160@60Hz

Audio

Input interface

input:3.5mm * 2 , output:3.5mm * 2

Signal type

Balanced/Unbalanced Stereo Audio

Signal format

AAC/AC3/AIF/FLAC/M44/MP3/MPC/OGG/WAV/WMA

Fiber optic

interface

4 dual core LC fiber optic interfaces

Fiber type

Single mode

wavelength

Single mode: 1310nm~1620nm

transmission distance

Single mode fiber optic 20km

USB

USB 2.0 interface

USB Type-C female interface * 1, USB 2.0 TypeA female interface * 4

Protocol type

USB 2.0, compatible with USB 1.1

Connecting devices

Connecting a computer to simulate a keyboard and mouse

Electrical specifications

source

DC 12V,1.5A

power dissipation

12W

size

220mm×165mm×44mm

weight

1.3kg

Working temperature and humidity

0℃-50℃,10%-90%

Storage temperature and humidity

-20℃-60℃,10%-90%

hours

365×24
